Two - Station PCB Separation CNC Drilling And Milling Machine
Feature:
1. Use the CW intelligence control system created by Chuangwei which has good stability and support network
program U drive disk, superior to other control systems of China
2. Use the frequency conversion system of Delta or adleepower, Such as the Processing speed could be improved
30% using 60000 turn spindle.
3. Using the high precision linear guide rail and high precision ball screw, made in Taiwan.
4. Each axis is driven by AC servo combination.
5. Control software: The software, Such as CAM350/V2001/GENESIS2000 product the ROU,ROT,NC,DRL,
GBR etc;
control software:
support to edit or auto-compensate ROU,ROT,NC,DRL,GBR which are processed by autosoftwares like
CAM350V2001.
And have functions such as graphical automatic optimization of machining path, hierarchical drill-down, simulation
process and autopromping
6. Machine cover:
International standards for the professional control box together with the hood times full steel structure
Technical parameters:
| Item | Description | Notes |
| Operating stroke(XYZ) | 550*650*60mm | Actual working range |
| Drilling Accuracy | ±0.02mm | |
| Rapid Positioning Speed | 25m/min | |
| Spindle Rotation Range | 40000 rmp | Spindle motor power 1.5kw |
| Drilling Diameter | 0.6-6.5mm | |
| Tool Change Mode | manual | ER11 |
| Controller Interface | Chinese/English | |
| Automatic stripping | selectable | selectable |
| Power Requirement | AC220V/50Hz / 4000W | |
| Dimension | 1820*1550*1450 mm | |
| Cooling mode(principal axis) | Circulating water cooling | |
| Machine Weight(kg) | 2000 | |
| Working Environment | Centigrade degree: 20-25℃, RH:75% | |
| Compressed air requirement | 0.5MPa | |
| Applicable | All PCB(MCPCB) drilling / milling |
Machine layout:
| Name | Brand | Country of origin | Notes |
| Guide | PMI | Taiwan, China | |
| Screw | TBI | Taiwan, China | |
| Principal axis | Chuangwei | China | |
| Servo System | Fuji | Japan | |
| Frequency spindle | Adleepower | Taiwan, China | High frequency |
| Computer | HP | China | 19 liquid crystal display (HP original) |
| The machine table | Jinanqin | Shandong, China | granite |
